NXP/Freescale i.MX6
Cortex™-A9 MPCore™
1-2 Cores (2-4 cores supported by the VAR-SOM-MX6_V2 SoM)
1 GHz
Up to 5,000
256 - 1024 MB DDR3
128 - 512 MB SLC NAND
8 - 128 GB
Vivante GC 880 + Vivante GC 320
1080p30 H.264 Decode, 1080p30 H.264 Encode
1x CSI, 1x CPI
v1.4 1920 x 1080
Dual 1366 x 768 24-bit
1280 x 720 24-bit
Resistive, Capacitive
Yes
Digital
S/PDIF
Yes
x1
USB 2.0 : 1x Host, 1x OTG
x5, up to 5 Mbps
x3
x3
On carrier
Gen 2.0
x2
10/100/1000 Mbps
Certified 802.11 a/b/g/n + MIMO
5.1 + CSA2 support / BLE
Yocto, Debian, Boot2Qt
Yes
67.8 x 33.0 mm
3.3 V
3.3 V
0 to 70°C
-20 to 70°C
-40 to 85°C
-40 to 85°C
5% to 95%
CPU type: SOLO : i.MX6 SOLO, DUAL : i.MX6 Dual Lite
Clock speed: 1000MHz : 1000C, 800MHz : 800C(Industrial)
RAM size: 256MB : 256R, 512MB : 512R, 1024MB : 1024R
NAND size: 128MB : 128N, 256MB : 256N, 512MB : 512N
eMMC size: 0GB: 0G, 8GB : 8G, 16GB : 16G, 32 GB : 32G, 64 GB : 64G
10/100/1000Mbps Ethernet PHY
Audio Codec
4-wire Touch Panel.
Note: Capacitive touch is natively supported through I2C in the base configuration
WB: Built-in certified Wi-Fi 802.11 b/g/n + Bluetooth 5.1 + CSA2 support/BLE (CT/ET only)
WBD: Built-in certified Wi-Fi 802.11 a/b/g/n with MIMO + Bluetooth 5.1 + CSA2 support/BLE
C : 0 to 70°C, E : -20 to 70°C, I : -40 to 85°C
