NXP iMX 8X
4x Cortex-A35
4 Cores
1.2 GHz Cortex™-A35
264MHz Cortex-M4F
HiFi 4 DSP
Up to 8,540
1 - 4 GB LPDDR4
8 - 128 GB
Vivante GC7000Lite
4K H.265 Decode, 1080p H.264 Encode/Decode
1x MIPI-CSI2, 1x parallel CSI 8/10-bit
Parallel LCD up to 720p60 24-bit
Dual 1920x1080 24-bit
MIPI-DSI 1920x1200 24-bit
Resistive, Capacitive
Yes
Digital, Analog (stereo)
ESAI/4x I2S(SAI), S/PDIF
Yes
x1
USB 3.0/2.0: 1x OTG, USB 2.0: 1x Host/Device
x6, up to 4 Mbps
x6
x4
3 x CAN/CAN-FD (Flexible Data-Rate)
On carrier
x1 (via optional header)
x1, 4x4 matrix
x1
Gen 3.0
6 x 12bit
2x 10/100/1000 Mbps
Certified 802.11 ac/a/b/g/n
BT/BLE 5.2
Yocto, Debian, Boot2Qt
Yes
Yes
67.6 x 51.6 mm
3.3 V
3.3 V
-25 to 85°C
-40 to 85°C
-40 to 85°C
5% to 95%
CPU type: QuadXPlus 4x Cortex A35: QP
CPU clock speed: 1200MHz Cortex A35: 1200C
LP-DDR4: 1024MB: 1024R, 2048 MB: 2048R, 4096 MB: 4096R
eMMC: 8 GB : 8G, 16 GB : 16G, 32 GB : 32G, 64 GB : 64G, 128 GB : 128G
Audio Codec
GbE PHY
Resistive touch panel controller
Built-in Certified Wi-Fi 802.11 ac/a/b/g/n + Bluetooth 5.2/BLE
With ADC and Cortex M4 UART (instead of QSPI/GPIOs)
E: -25 to 85°C, I: -40 to 85°C
